INMOST::ConstMatrixRepack< Var > Class Template Reference
Inheritance diagram for INMOST::ConstMatrixRepack< Var >:
Collaboration diagram for INMOST::ConstMatrixRepack< Var >:

Public Types

typedef AbstractMatrixReadOnly< Var >::enumerator enumerator

- Public Types inherited from INMOST::AbstractMatrixReadOnly< Var >
typedef unsigned enumerator


Public Member Functions

__INLINE enumerator Rows () const
 Number of rows. More...

__INLINE enumerator Cols () const
 Number of columns. More...

 ConstMatrixRepack (const AbstractMatrixReadOnly< Var > &rA, enumerator n, enumerator m)

 ConstMatrixRepack (const ConstMatrixRepack &b)

__INLINE Var compute (enumerator i, enumerator j) const
 Access element of the matrix by row and column indices without right to change the element. More...

__INLINE INMOST_DATA_ENUM_TYPE GetMatrixCount () const
 Retrieve number of indices of derivatives.

- Public Member Functions inherited from INMOST::AbstractMatrixReadOnly< Var >
bool CheckNans () const
 Check all matrix entries for not a number. More...

bool CheckInfs () const
 Check all matrix entries for infinity. More...

bool CheckNansInfs () const
 Check all matrix entries for not a number and infinity. More...

Var Det () const
 Matrix determinant.

bool SVD (AbstractMatrix< Var > &U, AbstractMatrix< Var > &Sigma, AbstractMatrix< Var > &V, bool order_singular_values=true, bool nonnegative=true) const
 Singular value decomposition. More...

bool cSVD (AbstractMatrix< Var > &U, AbstractMatrix< Var > &Sigma, AbstractMatrix< Var > &V) const
 Singular value decomposition. More...

ConstMatrixTranspose< Var > Transpose () const
 Transpose current matrix. More...

ConstMatrixConjugateTranspose< Var > ConjugateTranspose () const
 Transpose and conjugate current matrix. More...

ConstMatrixConjugate< Var > Conjugate () const
 Conjugate current matrix. More...

template<typename typeB >
Matrix< typename Promote< Var, typeB >::type > CrossProduct (const AbstractMatrixReadOnly< typeB > &other) const
 Cross-product operation for a vector. More...

template<typename typeB >
Matrix< typename Promote< Var, typeB >::type > Transform (const AbstractMatrixReadOnly< typeB > &other) const
 Transformation matrix from current vector to provided vector using shortest arc rotation. More...

template<typename typeB >
MatrixDifference< Var, typeB > operator- (const AbstractMatrixReadOnly< typeB > &other) const
 Subtract a matrix. More...

template<typename typeB >
MatrixSum< Var, typeB > operator+ (const AbstractMatrixReadOnly< typeB > &other) const
 Add a matrix. More...

template<typename typeB >
MatrixMul< Var, typeB, typename Promote< Var, typeB >::type > operator* (const AbstractMatrixReadOnly< typeB > &other) const
 Multiply the matrix by another matrix. More...

MatrixUnaryMinus< Var > operator- () const
 Unary minus. Change sign of each element of the matrix.

template<typename typeB >
KroneckerProduct< Var, typeB > Kronecker (const AbstractMatrixReadOnly< typeB > &other) const
 Kronecker product, latex symbol \otimes. More...

Matrix< Var > Invert (int *ierr=NULL) const
 Inverts matrix using Crout-LU decomposition with full pivoting for maximum element. More...

Matrix< Var > CholeskyInvert (int *ierr=NULL) const
 Inverts symmetric positive-definite matrix using Cholesky decomposition.

template<typename typeB >
Matrix< typename Promote< Var, typeB >::type > Solve (const AbstractMatrixReadOnly< typeB > &B, int *ierr=NULL) const
 Finds X in A*X=B, where A and B are general matrices. More...

template<typename typeB >
Matrix< typename Promote< Var, typeB >::type > CholeskySolve (const AbstractMatrixReadOnly< typeB > &B, int *ierr=NULL) const
 Finds X in A*X=B, where A is a square symmetric positive definite matrix. More...

Var Trace () const
 Calculate sum of the diagonal elements of the matrix. More...

void Print (INMOST_DATA_REAL_TYPE threshold=1.0e-10, std::ostream &sout=std::cout) const
 Output matrix to screen. More...

bool isSymmetric (double eps=1.0e-7) const
 Check if the matrix is symmetric. More...

template<typename typeB >
Promote< Var, typeB >::type DotProduct (const AbstractMatrixReadOnly< typeB > &other) const
 Computes dot product by summing up multiplication of entries with the same indices in the current and the provided matrix. More...

template<typename typeB >
Promote< Var, typeB >::type operator^ (const AbstractMatrixReadOnly< typeB > &other) const
 Computes dot product by summing up multiplication of entries with the same indices in the current and the provided matrix. More...

SelfPromote< Var >::type FrobeniusNorm () const
 Computes frobenius norm of the matrix. More...

Var MaxNorm () const
 Computes maximum absolute value of the matrix. More...

Matrix< Var > PseudoInvert (INMOST_DATA_REAL_TYPE tol=0, int *ierr=NULL) const
 Calculates Moore-Penrose pseudo-inverse of the matrix. More...

Matrix< Var > Power (INMOST_DATA_REAL_TYPE n, int *ierr=NULL) const
 Calcuate A^n, where n is some real value. More...

Matrix< Var > Root (INMOST_DATA_ENUM_TYPE iter=25, INMOST_DATA_REAL_TYPE tol=1.0e-7, int *ierr=NULL) const
 Calculate square root of A matrix by Babylonian method. More...

template<typename typeB >
Matrix< typename Promote< Var, typeB >::type > PseudoSolve (const AbstractMatrixReadOnly< typeB > &B, INMOST_DATA_REAL_TYPE tol=0, int *ierr=NULL) const
 Solves the system of equations of the form A*X=B, with A and B matrices. More...

Matrix< Var > ExtractSubMatrix (enumerator ibeg, enumerator iend, enumerator jbeg, enumerator jend) const
 Extract submatrix of a matrix. More...

ConstMatrixRepack< Var > Repack (enumerator rows, enumerator cols) const
 Change representation of the matrix into matrix of another size. More...

ConstSubMatrix< Var > operator() (enumerator first_row, enumerator last_row, enumerator first_col, enumerator last_col) const
 Extract submatrix of a matrix for in-place manipulation of elements. More...

ConstBlockOfMatrix< Var > BlockOf (enumerator nrows, enumerator ncols, enumerator offset_row, enumerator offset_col) const
 Define matrix as a part of a matrix of larger size with in-place manipulation of elements. More...

template<typename typeB >
MatrixMulCoef< Var, typeB, typename Promote< Var, typeB >::type > operator* (const typeB &coef) const
 Multiply the matrix by a coefficient. More...

template<class A >
MatrixMulShellCoef< Var, shell_expression< A >, typename Promote< Var, variable >::type > operator* (shell_expression< A > const &coef) const
 Multiply the matrix by a coefficient. More...

template<typename typeB >
MatrixDivCoef< Var, typeB, typename Promote< Var, typeB >::type > operator/ (const typeB &coef) const
 Divide the matrix by a coefficient of a different type. More...

template<class A >
MatrixDivShellCoef< Var, shell_expression< A >, typename Promote< Var, variable >::type > operator/ (shell_expression< A > const &coef) const
 Divide the matrix by a coefficient of a different type. More...

template<typename typeB >
Matrix< typename Promote< Var, typeB >::type > operator/ (const AbstractMatrixReadOnly< typeB > &other) const
 Performs B^{-1}*A, multiplication by inverse matrix from left. More...

ConstMatrixConcatCols< Var > ConcatCols (const AbstractMatrixReadOnly< Var > &B) const
 Concatenate B matrix as columns of current matrix. More...

template<typename VarB >
ConstMatrixConcatCols2< Var, VarB, typename Promote< Var, VarB >::type > ConcatCols (const AbstractMatrixReadOnly< VarB > &B) const
 Concatenate B matrix as columns of current matrix. More...

ConstMatrixConcatRows< Var > ConcatRows (const AbstractMatrixReadOnly< Var > &B) const
 Concatenate B matrix as rows of current matrix. More...

template<typename VarB >
ConstMatrixConcatRows2< Var, VarB, typename Promote< Var, VarB >::type > ConcatRows (const AbstractMatrixReadOnly< VarB > &B) const
 Concatenate B matrix as rows of current matrix. More...

virtual ~AbstractMatrixReadOnly ()
 Destructor.

__INLINE Matrix< Promote< variable, variable >::type > CholeskySolve (const AbstractMatrixReadOnly< variable > &B, int *ierr) const

__INLINE Matrix< Promote< INMOST_DATA_REAL_TYPE, variable >::type > CholeskySolve (const AbstractMatrixReadOnly< variable > &B, int *ierr) const

__INLINE Matrix< Promote< variable, INMOST_DATA_REAL_TYPE >::type > CholeskySolve (const AbstractMatrixReadOnly< INMOST_DATA_REAL_TYPE > &B, int *ierr) const


Additional Inherited Members

- Static Protected Attributes inherited from INMOST::AbstractMatrixBase
static thread_private< Sparse::RowMergermerger


Detailed Description

template<typename Var>
class INMOST::ConstMatrixRepack< Var >

Definition at line 3055 of file inmost_dense.h.

Member Function Documentation

◆ Cols()

template<typename Var >
__INLINE enumerator INMOST::ConstMatrixRepack< Var >::Cols ( ) const
inlinevirtual

Number of columns.

Returns
Number of columns.

Implements INMOST::AbstractMatrixReadOnly< Var >.

Definition at line 3069 of file inmost_dense.h.

◆ compute()

template<typename Var >
__INLINE Var INMOST::ConstMatrixRepack< Var >::compute ( enumerator  i,
enumerator  j
) const
inlinevirtual

Access element of the matrix by row and column indices without right to change the element.

Parameters
iRow index.
jColumn index.
Returns
Reference to constant element.

Implements INMOST::AbstractMatrixReadOnly< Var >.

Definition at line 3078 of file inmost_dense.h.

◆ Rows()

template<typename Var >
__INLINE enumerator INMOST::ConstMatrixRepack< Var >::Rows ( ) const
inlinevirtual

Number of rows.

Returns
Number of rows.

Implements INMOST::AbstractMatrixReadOnly< Var >.

Definition at line 3066 of file inmost_dense.h.


The documentation for this class was generated from the following files:
